FJ6/HT Series DIN Rail Aluminum Terminal Block

Product Features

Designed for large cross-section conductors and high-current conductor termination.
Suitable for aluminum and aluminum-copper conductors (Al/Cu).
Aluminum conductor structure provides good corrosion resistance for long-term operation.
Lightweight design for convenient installation and handling.
Cost-effective solution for high-current conductor connection applications.
Screw clamping connection ensures reliable mechanical strength and stable electrical contact.
DIN rail-mounted structure suitable for modular wiring systems.

Detailed introduction

Application

The FJG/HT series DIN rail aluminum terminal blocks are designed for reliable conductor termination and connection in low-voltage electrical systems using aluminum and aluminum-copper conductors.

They are suitable for large cross-section conductors and high-current applications, and are widely used in control cabinets, switchgear assemblies, power distribution panels, transformer terminals, and main power connection points.

Key Specifications

Key Specifications	HT-50	HT-50/2	HT-50/3	HT-95	HT-150	HT-240
Electrical Specifications
Rated Insulation Voltage(V)	1000	1000	1000	1000	1000	1000
Rated Current(A)	160	160	160	245	320	425
Standard	IEC 60947-7-1	IEC 60947-7-1	IEC 60947-7-1	IEC 60947-7-1	IEC 60947-7-1	IEC 60947-7-1
Conductor & Connection Specifications
Solid Conductor Range(mm²)	16-50	16-50	16-50	16-95	50-150	95-240
Stranded Conductor Range(mm²)	16-50	16-50	16-50	16-95	50-150	95-240
Conductor Entry Direction	Side entry line	Side entry line	Side entry line	Side entry line	Side entry line	Side entry line
Material & Environmental Specifications
Insulation Material	PA66	PA66	PA66	PA66	PA66	PA66
Pollution Degree	3	3	3	3	3	3
Color	Customize	Customize	Customize	Customize	Customize	Customize
Installation and Operation
Thickness(mm)	17.7	29.8	49.6	42	28.6	37
Width(mm)	51.2	49.2	51	89	98	130
Height(mm)	45.3	45.3	43	51	60.5	66
–
Order Number

Installation and Operation

Mounts directly onto standard TH-35 DIN rails.
Fully insert the conductor into the clamping chamber and tighten the screw to the specified torque.
Ensure the conductor size and rated current match the selected model.
Suitable for aluminum and aluminum-copper conductor termination and connection.

Installation Notes

Installation and wiring shall be carried out with the power supply disconnected.
Ensure the conductor is fully inserted into the clamping area during wiring.
When using large cross-section aluminum conductors, ensure proper alignment before tightening.
Tighten the screw according to the specified torque to ensure reliable electrical contact.
